History of the TBM:
Design and Development:
Douglas' TBD Devastator, the U.S. Navy's main torpedo bomber introduced in 1935 was obsolete by 1939. Bids were accepted from several companies but Grumman's TBF design was selected as the TBD's replacement. Designed by Leroy Grumman, its first prototype was called the XTBF-1. Although one of the first two prototypes crashed near Brentwood, New York, rapid production continued.

Grumman's first torpedo bomber was the heaviest single-engine aircraft of World War II, and it was the first design to feature a new wing-folding mechanism created by Grumman, intended to maximize storage space on an aircraft carrier; the F4F-4 and later models of Wildcat received a similar folding wing and the F6F Hellcat (both designed by Grumman) would employ this mechanism as well.

The engine used was the Wright R-2600-20 (which produced 1,900 horsepower). There were three crew members: pilot, turret gunner and radioman/bombardier/ventral gunner. One .30-caliber machine gun was mounted in the nose, a .50 caliber gun was mounted right next to the turret gunner's head in a rear-facing electrically powered turret, and a single .30 caliber hand-fired machine gun mounted ventrally (under the tail), which was used to defend against enemy fighters attacking from below and to the rear. This gun was fired by the radioman/bombardier while standing up and bending over in the belly of the tail section, though he usually sat on a folding bench facing forward to operate the radio and to sight in bombing runs.

Later models of the TBF/TBM dispensed with the nose-mounted gun for one .50 caliber gun in each wing per pilots' requests for better forward firepower and increased strafing ability. There was only one set of controls on the aircraft, and no access to the pilot's position from the rest of the aircraft. The radio equipment was massive, especially by today's standards, and filled the whole glass canopy to the rear of the pilot. The radios were accessible for repair through a "tunnel" along the right hand side. Any Avengers that are still flying today usually have an additional rear-mounted seat in place of the radios, which increases the number of crew to four.

The Avenger had a large bomb bay, allowing for one Bliss-Leavitt Mark 13 torpedo, a single 2000 lb (900 kg) bomb, or up to four 500 lb (230 kg) bombs. The aircraft had overall ruggedness and stability, and pilots say it flew like a truck, for better or worse. With its good radio facilities, docile handling, and long range, the Grumman Avenger also made an ideal command aircraft for Commanders, Air Group (CAGs). With a 30,000 ft (10,000 m) ceiling and a fully-loaded range of 1,000 miles (1,600 km), it was better than any previous American torpedo bomber, and better than its Japanese counterpart, the obsolete Nakajima B5N "Kate". Later Avenger models carried radar equipment for the ASW and AEW roles. Although improvements in new types of aviation radar were soon forthcoming from the engineers at MIT and the electronic industry, the available radars in 1943 were very bulky, because they contained vacuum tube technology. Because of this, radar was at first carried only on the roomy TBF Avengers, but not on the smaller and faster fighters.

Escort carrier sailors referred to the TBF as the "turkey" because of its size and maneuverability in comparison to the F4F Wildcat fighters in CVE airgroups.[1]

Operational History
On the afternoon of 7 December 1941, Grumman held a ceremony to open a new manufacturing plant and display the new TBF to the public. Coincidentally, on that day, the Imperial Japanese Navy attacked Pearl Harbor, as Grumman soon found out. After the ceremony was over, the plant was quickly sealed off to ward against possible enemy action. By early June 1942, a shipment of more than 100 aircraft was sent to the Navy (although most were too late to participate in the pivotal Battle of Midway). However, six TBF-1s were present on Midway Island, as part of VT-8 (Torpedo Squadron 8), while the rest of the squadron flew Devastators from the Hornet. Unfortunately, most of the pilots had very little previous experience, and only one TBF survived (with heavy damage and casualties). As author Gordon Prange mentions in Miracle at Midway, the outdated Devastators (and lack of new aircraft) contributed somewhat to the lack of a complete victory.

On 24 August 1942, the next major naval battle occurred at the Eastern Solomons. With only the carriers USS Saratoga (CV-3) and Enterprise, the 24 TBFs present were able to sink the Japanese aircraft carrier Ryujo and claim one dive bomber, at the cost of seven aircraft. The first major "prize" for the TBFs (which had been assigned the name "Avenger" in October 1941, before the Japanese attack on Pearl Harbor) was at the Naval Battle of Guadalcanal in November 1942, when Marine Corps and Navy Avengers helped sink the battleship Hiei.

After hundreds of the original TBF-1 models were built, the TBF-1C began production. The allotment of space for specialized internal and wing-mounted fuel tanks doubled the Avenger's range. By 1943, Grumman began to slowly phase out production of the Avenger to produce F6F Hellcat fighters, and the Eastern Aircraft Division of General Motors took over, with these aircraft being designated TBM. Starting in mid-1944, the TBM-3 began production (with a more powerful powerplant and wing hardpoints for drop tanks and rockets). The dash-3 was the most numerous of the Avengers (with about 4,600 produced). However, most of the Avengers in service were dash-1s until near the end of the war (in 1945).

Besides the traditional surface role (torpedoing surface ships), Avengers claimed about 30 submarine kills, including the cargo submarine I-52. They were one of the most effective sub-killers in the Pacific theatre, as well as in the Atlantic, when escort carriers were finally available to escort Allied convoys. There, the Avengers contributed in warding off German U-Boats while providing air cover for the convoys.

After the "Marianas Turkey Shoot", in which more than 250 Japanese aircraft were downed, Admiral Marc Mitscher ordered a 220-aircraft mission to find the Japanese task force. At the extreme end of their range (300 nautical miles out), the group of Hellcats, TBF/TBMs, and dive bombers took many casualties. However, Avengers from USS Belleau Wood (CVL-24) torpedoed the light carrier Hiyo as their only major prize. Mitscher's gamble did not pay off as well as he had hoped.

In June 1943, future-President George H.W. Bush became the youngest naval aviator at the time. While flying a TBM with VT-51 (from the USS San Jacinto (CVL-30)), his TBM was shot down on 2 September 1944 over the Pacific island of Chichi Jima. Both of his crewmates died; however, because he released his payload and hit the target before being forced to bail out, he received the Distinguished Flying Cross.

Another famous Avenger aviator was Paul Newman, who flew as a rear gunner. He had hoped to be accepted for pilot training, but did not qualify because of being color blind. Newman was onboard the escort carrier USS Hollandia (CVE-97) roughly 500 miles from Japan when the Enola Gay dropped the first atomic bomb on Hiroshima.

TBF/TBMs sank the two Japanese "super battleships": the Musashi and the Yamato (which was Admiral Isoroku Yamamoto's flagship for most of the war). The Avengers played a major role in the Allied victory during World War II, although torpedoes had become largely outdated (replaced by the faster and more effective dive bombers) by then.

The Avenger was also used by the Royal Navy's Fleet Air Arm where it was initially known as the "Tarpon" however this name was later discontinued and the Avenger name used instead. The first 402 aircraft were known as Avenger Mk 1, 334 TBM-1s from Grumman were the Avenger Mk II and 334 TBM-3 the Mark III. Post war the antisubmarine version was the "Avenger AS Mk IV" in RN service.

The only other operator in World War II was the Royal New Zealand Air Force which used the TBM Avenger type of aircraft primarily as a bomber, operating from South Pacific Island bases. Some of these were transferred to the British Pacific Fleet.

In 1945 Avengers were involved in pioneering trials of aerial topdressing in New Zealand that led to the establishment of an industry which markedly increased food production and efficiency in farming worldwide. Pilots of the Royal New Zealand Air Force's 42 Squadron spread fertilizer from Avengers beside runways at Ohakea air base.

One of the primary postwar users of the Avenger was the Royal Canadian Navy, which obtained 125 former US Navy TBM-3E Avengers from 1950 to 1952 to replace their venerable Fairey Fireflies. By the time the Avengers were delivered, the RCN was shifting its primary focus to anti-submarine warfare (ASW), and the aircraft was rapidly becoming obsolete as an attack platform. Consequently, 98 of the RCN Avengers were fitted with an extensive number of novel ASW modifications, including radar, electronic countermeasures (ECM) equipment, and sonobuoys, and the upper ball turret was replaced with a sloping glass canopy that was better suited for observation duties.

The modified Avengers were designated AS 3. A number of these aircraft were later fitted with a large magnetic anomaly detector (MAD) boom on the rear left side of the fuselage and were redesignated AS 3M. However, RCN leaders soon realized the Avenger's shortcomings as an ASW aircraft, and in 1954 they elected to replace the AS 3 with the S-2 Tracker, which offered longer range, greater load-carrying capacity for electronics and armament, and a second engine, a great safety benefit when flying long-range ASW patrols over frigid North Atlantic waters. As delivery of the new license-built CS2F Trackers began in 1957, the Avengers were shifted to training duties, and were officially retired in July 1960.
